SS kitchen basin Titanium Nitride Coating Machine, TiN gold decorative coating on kitchenwares

Name: SS kitchen basin Titanium Nitride Coating Machine TiN gold decorative coating on kitchenwares
Brand: ROYAL
Price: 1 USD

China SS kitchen basin Titanium Nitride Coating Machine, TiN gold decorative coating on kitchenwares wholesale

Brand Name : ROYAL

Model Number : RTAC

Certification : CE

Place of Origin : Made in China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 15 sets per month

Delivery Time : 12 weeks

Packaging Details : Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.

Vacuum Technology : Arc evaporation, Arc Ion Plating

Deposition Sources : Cylinder arc or circular arc cathodes

Coating Films : Metal film plating, Titanium Nitride, Titanium Carbide, Zirconium Nitride, Chromium Nitride, TiAlN, CrC

Industrial Applications : Ceramic and glass house wares, stainless steel table ware, steel sheet, furniture, table, chair, watches and clocks, hard coatings on tools

Factory Location : Shanghai city, China

Worldwide Service : Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America

Training Service : Machine operation, maintenance, coating process Recipes, program

Warranty : Limited warranty 1 year for free, whole life for machine

OEM & ODM : available, we support tailor made design and fabrication

Contact Now

Stainless Steel Pot Titanium Nitride Coating Machine, TiN gold decorative coating on stainless steel kitchenware

TiN Gold Coating Machine Advantages

1. Economically efficient, generating the thinnest, most uniform coating films;
2. A dry coating process at low temperature in a vacuum chamber;
3. Offers great versatility and can be used for the deposition of conductive or non-conductive materials on any type of substrates, like: metals, ceramics, plastic materials.
4. Multi-layered coating are simple to produce.

5. Fast deposition rates and high quality surface finishes.

Advantages
Many bright colors of final finishings
Excellent scratch resistance
Enables longer life of products
Environmentally-friendly process
Robust and high volume design machine
HMI friendly operation system
Low maintenance
Low cost of ownership

Applications
Bathroom and shower fixtures
Sanitary ware and plumbing applies
Door handles, fasteners, safe and locks
Glass and ceramic products
Eyewear
Writing Instruments

Only to name a few, but for more applications, please contact Royal Technology

Tableware TiN Gold Coating Machine Specifications

MODEL				RTAC1215
TECHNOLOGY				Magnetron Sputtering + Ion Plating
MATERIAL				Stainless Steel (S304)
CHAMBER SIZE				Φ1200*H1500mm
CHAMBER TYPE				Cylinder, vertical, 1-door

DEPOSITION MATERIAL				Aluminum, Silver, Copper, Chrome, Stainless Steel, Nickel, Gold, TiAl, Au alloy, Ag etc.
DEPOSITION SOURCE				14 sets steered arc cathodes
GAS				MFC- 4 ways, Ar, N2, O2, C2H2
CONTROL AND OPERATION				PLC(Programmable Logic Controller) + Touch Screen
PUMP SYSTEM				SV300B - 2 sets (Leybold)
				WAU1001 - 1 sets (Leybold)
				D60T- 1 set (Leybold)
				Turbo Molecular Pumps: 3* F-400/3500
PRE-TREATMENT				Bias power supply: 1*36 KW
SAFETY SYSTEM				Numerous safety interlocks to protect operators
COOLING				Cold Water
POWER ELECTRICAL				480V/3 phases/60HZ ( USA compliant)
				460V/3 phases/50HZ ( Asia compliant)
				380V/3 phases/50HZ ( EU-CE compliant)
FOOTPRINT				L3000W3000H2000mm
TOTAL WEIGHT				7.0 T
FOOTPRINT				( LWH) 50004000 4000 MM
CYCLE TIME				30~40 minutes (depending on substrate material, substrate geometry and environmental conditions)
POWER MAX..				155 KW
AVERAGE POWER CONSUMPTION (APPROX.)				75 KW

SS kitchen basin Titanium Nitride Coating Machine, TiN gold decorative coating on kitchenwares

Why us?

Advanced production machineries (milling, welding,cutting,vacuum leak testing)combined with standardized production procedures and strict tests enable Royal Technology to produce high quality, reliable and low cost coating systems.
Quality, service and on-time delivery are the core principles of Royal technology’s business. A strategy of openly outsourcing simple components to professional manufactures allows us to focus attention to key parts and components R&D, manufacturing.
Strict quality control policies and rigorous selection of qualified suppliers assure Royal Technology’s customers receive the most advanced, high-end quality equipment at the most affordable cost.

Please contact us for more specifications, Royal Technology is honored to provide you total

coating solutions.
