ABS Chrome PVD Gold Plating Machine / Automotive ABS Parts Copper Color Coating by Arc Evaporation

Name: ABS Chrome PVD Gold Plating Machine Automotive ABS Parts Copper Color Coating by Arc Evaporation
Brand: ROYAL
Price: 1 USD

China ABS Chrome PVD Gold Plating Machine / Automotive ABS Parts Copper Color Coating by Arc Evaporation wholesale

Brand Name : ROYAL

Model Number : RTAS1616

Certification : CE

Place of Origin : Made in China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 15 sets per month

Delivery Time : 8 to 12 weeks

Packaging Details : Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.

Vacuum Technology : Cathodic Multi Arc plating, PVD arc evaporation, magnetron Sputtering MF

Deposition Sources : Cathodic arc sources + MF Sputtering cathodes

Coating Films : Metal film plating, Titanium Nitride, Titanium Carbide, Zirconium Nitride, Chromium Nitride, TiAlN, CrC

Industrial Applications : Faucets and bathroom fittings, Metal, Ceramic and glass house wares, stainless steel table ware, steel sheet, furniture, table, chair, watches and clocks, hard coatings on tools

Factory Location : Shanghai city, China

Worldwide Service : Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America

Training Service : Machine operation, maintenance, coating process Recipes, program

Warranty : Limited warranty 1 year for free, whole life for machine

OEM & ODM : available, we support tailor made design and fabrication

Contact Now

ABS Chrome PVD Gold Plating Machine / Automotive ABS Parts Copper Color Coating by Arc Evaporation

Summary:

Car as important transporation vehile of our daily life, consumers and manufactures are more focusing on the creative design & surface treatment process. PVD vacuum Ion Plating is used to replace the traditional chemical electro-plating is more recommended due to its low production cost, 100% friendly environmentally, flexible operation features.

PVD vacuum coatings properties

Exceptional aesthetic finish
Uniform coating thickness
Superior resistance to wear and corrosion
PVD coating has a high level of hardness

PVD Coating Machine Advantages:

1. High ionization rate, high through put,
2. Large capacity to satisfy mass production,

3. Excellent film adhesion and various colors are available.

4. Coating lMateria: Chrome, Titanium, Zr , TiAl, etc.

The multi arc + MF sputtering deposition coater is exclusively designed for brass faucets industries, it can coat the whole set of faucets, plumbing, valves etc.

The advantages

1. Equipped with cryo-pump (Polycold) device, which

Is available for plastic parts, like ABS, PC, ABS + PC, PP materials plating.

2. MF sputtering cathodes and DC Sputtering Cathodes for option.

TECHNICAL SPECIFICATION:

MODEL	RTAS1616
MATERIAL	Stainless Steel
CHAMBER SIZE	Φ1600*1600mm (H)
PUMP SYSTEM	Rotary Piston Vacuum Pump (Mechanical)
	Rotary Vane Vacuum Pump (Holding)
	Roots Vacuum Pump
	Turbo Molecular Pump
TECHNOLOGY	Ion Plating ( Multi-arc sources) + Pulsed Bias Plasma Cleaning
RACK SYSTEM	Planetary Rods: 10
TYPICAL TARGETS	Titanium, Zirconium, Chrome, TiAl etc.
GAS	Gas Mass Flow Meters ( Ar, N_2, C₂H₂, O₂) Argon, Nitrogen and Ethyne,Oxygen
CONTROL	PLC(Programmable Logic Controller)
SAFETY SYSTEM	Numerous safety interlocks to protect operators and equipment
COOLING	Water
HEATING	Heater
POWER MAX.	130KW (Approx.)
AVERAGE POWER	70KW (Approx.)

ZrN gold faucets PVD plating machine

ABS Chrome PVD Gold Plating Machine / Automotive ABS Parts Copper Color Coating by Arc Evaporation

Samples

Customized sizes of machine are available based on product dimensions and capacity requests.

Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
